Print Specifications

• Print Speed
  Single sided: Up to 38 ppm (A4)
  Up to 63.1 ppm (A5-Landscape)
  Double sided: Up to 31.9 ipm (A4)
• Printing Method
  Monochrome laser beam printing
• Print Resolution
  Up to 1200 x 1200 dpi
• Warm-up Time
  Approx. 14 seconds or less from power on
• First-Print-Out Time
  Approx. 5.5 seconds or less
• Printer Languages
  UFRII, PCL 5e³, PCL6, Adobe® PostScript3
• Fonts
  45 PCL fonts, 136 PS fonts
• Print Margins
  5 mm-top, bottom, left and right
• Advanced Printing Features
  Secure Print
  iOS: AirPrint, Canon PRINT Business app
  Android; Mopria certified, Canon Print Service Plug-in, Canon PRINT Business app

Media Handling

• Paper Input (Standard)
  250-sheet cassette
  100-sheet multi-purpose tray
• Paper Input (Option)
  550-sheet cassette
• Maximum Paper Input Capacity
  Up to 900 sheet
• Paper Output
  150-sheet
• Media Types
  Plain paper, Recycled paper, Heavy Paper, Thin paper, Colour paper, Coated paper, Label, Post card, Envelope
• Media Sizes
  Cassette:
  A4, A5, A5 (Landscape), B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelop (COM10, DL, C5, Monarch), Custom sizes: Min. 76.2 x 127 mm  Max. 216.0 x 355.6 mm.

  Multi-purpose tray:
  A4, A5, A5 (Landscape), B5, Legal, Letter, Executive, Statement, OFFICIO, B-OFFICIO, M-OFFICIO, GLTR, GLGL, Foolscap, 16K, Post card, Indexcard, Envelope (COM10, DL, C5, Monarch), Custom sizes: Min 76.2 x 127 mm  Max. 216.0 x 355.6 mm.

• Media Weights
  Cassette (standard and optional): 60 to 120 g/m²
  Multi-purpose tray : 60 to 163 g/m²
• Double Sided Printing
  A4, Legal, Letter, OFFICIO, B-OFFICIO, M-OFFICIO, GLGL, Foolscap
  Custom size – Min. 210 x 279.4 mm Max. 216.0 x 355.6 mm
  60 to 120 g/m²

Interface & Software

• Interface Type
  USB 2.0 Hi-Speed, 10BASE-T/100BASE-TX/1000Base-T, Wireless 802.11b/g/n, Wireless Direct Connection
• Operating System Compatibility
  Windows® 11 / Windows® 10 / Windows® 8.1 / Server® 2022
  Mac OS X version 10.11 & up
  Linux⁴
• Network Protocol
  Print:
  TCP/IP (LPD/Port9100/IPP/IPPS/WSD)

  Management:
  SNMPv1, SNMPv3 (IPv4, IPv6)

  Security: TLS1.3, IPSec, IP/Mac address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
  Security (wireless):
  Infrastructure Mode:
  WEP (64/128 bit), WPA-PSK(TKIP/AES), WPA2-PSK (TKIP/AES)
  Access Point Mode:
  WPA2-PSK (AES)

• Software and Printer Management
  Remote User Interface (RUI),
  Department ID Management,
  Toner Status Tool,
  iW Enterprise Management Console: Server-based software for centralised management of a fleet of devices
  eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics.

General Features

• Recommended Monthly Print Volume
  750 – 4,000 pages per month
• Duty Cycle
  80,000 pages
• Processor Speed
  800MHz x 2
• Memory
  1GB
• Control Panel
  5 Line LCD, 3 LED (Job, Error, Energy saver), Buttons, 10-key numeric keypad
• Dimensions with Trays (W x D x H)
  401 mm x 373 mm x 250 mm
• Weight
  Approx. 9.5 Kg
• Operating Environment
  Temperature: 10 to 30ºC (50 to 86ºF)
  Humidity 20 to 80% RH (no condensation)
• Power Source
  220-240V (±10%)  50/60Hz (±2Hz)
• Power Consumption
  Maximum: Approx. 1,330 W
  Standby: Approx. 9 W
  Sleep mode: Approx. 0.9 W
  Typical Electricity Consumption (TEC): 0.30 kWh/week (230V) ⁷
  For detailed information relating to Lot26 regulation, please go to:  http://www.canon-europe.com/For_Work/Lot26/index.aspx
• Noise Levels
  Sound Pressure¹:
  Active: 54 dB
  Standby: Inaudible²

  Sound Power¹:
  Active:  68 dB
  Standby: Inaudible²

Consumables

• Cartridges
  Cartridge 057 (3,100 pages ⁵)⁶
  Cartridge 057H (10,000 pages ⁵)⁶

Accessories & Options

• Items
  Cassette Feeding Module-AH1
